DC-AC voltage converter (pure sine) RUBRUKS NPI-360-220-7

Article: NPI-360-220-7

0 Р

Place an order

Get a consultation

Download a 3D model

Manufacturer:

RUBRUKS

• Maximum power, kW - 7
• Input voltage, V - 320...420
• Output voltage, V – 220

To share:

Specifications
Description

Maximum power, kW	7
Rated power, kW	6
Input voltage, V	320...420
Output voltage, V	220
Overall dimensions, mm	342x290x91
Weight, kg	14,88
Interface	CAN 2.0B
Type of cooling system	liquid

Available in intrinsically safe and explosion-proof versions

Manufacturer: RUBRUKS

The RUBRUKS NPI-360-220-7 DC-AC voltage converter (pure sine) is designed to convert direct current on board a vehicle into alternating 220 V pure sine for connecting domestic consumers.
Suitable for electric vehicles, hybrid vehicles and agricultural machinery.

Features:

“pure sine” - for powering any consumers of a household/industrial network
output current and voltage control
CAN interface
overload protection
overheat protection
automatic restoration of operation after eliminating the causes of protection activation
soft start (optional)
phase-by-phase unbalanced load compensation

Available in intrinsically safe and explosion-proof versions

You can place an order for DC-AC voltage converter (pure sine) RUBRUKS NPI-360-220-7 at Рубрукс by sending an application by mail , as well as by phone or at the company's office .
